We'll assume that you are using a common anode LEDs in the strip. If you have a transistor or constant current LED driver, you canĪlso use it to control an RGB LED strip or a higher power RGB LED.
RGB COMMON ANODE ARDUINO CODE
This example code works with an individual common anode and common cathode The brightness, type of LED, and rate at which the colors cycle. This code will cycle through 12 colors and white. = DESCRIPTION =Įxpand your color options using analogWrite() and a non-addressable RGB LED. WRITTEN BY: Ho Yun "Bobby" Chan SparkFun Electronicsįirmware developed using Arduino IDE v1.8.9 Non-Addressable RGB LED Custom Color Cycle Then hit the upload button to upload to your Arduino. Select the board (in this case the Arduino/Genuino Uno) and COM port that the board enumerated to. You can also copy the code below and paste it into the Arduino IDE. \ Non-Addresssable_RGB_LED_Strip_Code \ Firmware \ Arduino \ Example1_RGB-CycleLED. The path of the example code will probably look similar to. If you have not already, unzip the GitHub repo and open the example code called Example1_RGB-CycleLED.ino. There are options to adjust the brightness, type of LED, and rate at which the colors cycle. This is useful to test to see if you wired the colors correctly or want to show a color. Just make sure to check the datasheet to verify that there are channels for each color and include the appropriate parts if you are connecting them to a microcontroller. SMD Common Cathode RGB LED on a Sewable PCB Note: While the example code included in the tutorial was written for analog LED strips, this can also work for individual common anode LEDs, common cathode LEDs, and high power RGB LEDs as well! You'll eventually want to solder the LED strip to header pins, a prototyping board, or splice a 4-pin pigtail connector for a secure connection when using it in an installation.īasic Arduino Hookup w/ N Channel MOSFETSīuttons and Potentiometers Added for Additional Functionality For testing purposes, we'll use a breadboard, jumper wires, and alligator clips to connect. For additional functionality, you could add buttons and a potentiometer to control the LEDs. The hookup diagram for a basic connection is shown on the left. Each color channel requires a transistor to switch. Therefore, we'll be adding the load on the high side.
N-channel mosfets usually can handle more power and they are more power efficient. Typically for common anode RGB LED strips, you could use NPN BJTs or N-channel MOSFETs as a switch.
RGB COMMON ANODE ARDUINO SOFTWARE
You could also try to use software PWM on a Pi. If you are using a single board computer, you would probably need a dedicated PWM chip or DAC to control all three channels of the RGB LED strip. Heads up! Single board computers like the Raspberry Pi are limited in the number of PWM pins.
